Parker 12F32EC Coalescing Filter 120 Cfm 1/2 Inch Port

Product Description

The PARKER 12F32EC is a coalescing filter designed to remove oil aerosols, fine particulates, and water droplets from compressed air lines. Rated at 120 CFM with a 0.01 micron filtration rating, it delivers clean, dry air to downstream equipment and instrumentation. The polycarbonate bowl provides visible contamination monitoring, and the manual drain allows for routine maintenance without line interruption. This filter is sized for a 1/2 inch port and is rated to 150 psi maximum working pressure. Compressed air technicians and pipefitters install this type of unit as part of a point-of-use filtration train in industrial, commercial, and light manufacturing environments.

This filter fits inline on compressed air systems where high-efficiency coalescing is required before sensitive pneumatic tools, controls, or instrumentation. The modular connection design allows it to be integrated into multi-unit filter-regulator-lubricator assemblies or installed as a standalone unit. Typical applications include production lines, spray finishing systems, and instrument air headers where oil and moisture contamination must be controlled to low levels.

Key Features

• 0.01 micron filtration rating removes fine oil aerosols and sub-micron particulates
• 120 CFM flow capacity suits moderate to high-demand compressed air applications
• 150 psi maximum working pressure for standard industrial compressed air systems
• Polycarbonate bowl allows visual inspection of accumulated contaminants
• Manual drain for controlled removal of collected liquids during maintenance
• Modular connection supports integration into multi-stage filtration assemblies

Compatibility

Designed as an OEM-style replacement or new-installation coalescing filter for compressed air systems with a 1/2 inch port connection and modular filter assembly configurations.

Installation Notes

Installation is performed by licensed pipefitters or qualified compressed air system technicians. Depressurize and lock out the compressed air supply before installing or servicing this filter. Mount the unit with the bowl oriented downward to allow gravity drainage of collected liquids. Follow applicable OSHA compressed air safety standards and the manufacturer installation instructions for torque and seal specifications.
