Parker 12AT110BBPGN12H Hydraulic Filter Assembly 10 Micron

Product Description

The PARKER 12AT110BBPGN12H is a hydraulic filter assembly designed to remove contaminants from hydraulic fluid in pressurized fluid power systems. It uses a 10-micron microglass fiberglass filter media to capture fine particulate before it reaches sensitive hydraulic components such as valves, cylinders, and pumps. The assembly body is constructed from low carbon steel and aluminum, with a nitrile seal and a 3/4-inch NPTF threaded port for direct inline installation. Rated to 150 psi maximum operating pressure, it handles a service temperature range of -40 to 225 degrees F. Licensed hydraulic or industrial maintenance technicians are the primary installers of this assembly.

This filter assembly is suited for use in industrial and mobile hydraulic systems where inline filtration is required at low to moderate system pressures. The 3/4-inch NPT port size fits standard hydraulic line connections common in machine tool, agricultural, and light industrial equipment applications. It is appropriate for use in both return-line and low-pressure supply-line positions where 10-micron filtration is specified by the system designer or OEM.

Key Features

• 10-micron microglass fiberglass media for fine particulate removal
• 150 psi maximum operating pressure rating
• Service temperature range of -40 to 225 degrees F
• Low carbon steel and aluminum body construction for durability and weight balance
• 3/4-inch NPTF threaded port for standard inline installation
• Nitrile seal material compatible with most petroleum-based hydraulic fluids

Compatibility

Designed as an OEM-style inline hydraulic filter assembly for hydraulic systems using 3/4-inch NPT connections and operating within 150 psi and a temperature range of -40 to 225 degrees F.

Installation Notes

Installation should be performed by a qualified hydraulic technician or industrial maintenance professional. Depressurize and lock out the hydraulic system completely before removing or installing any filter assembly. Use appropriate thread sealant rated for hydraulic service on NPTF connections and avoid overtightening, which can damage the port threads or body. Verify that the system operating pressure does not exceed the 150 psi rated maximum before returning the system to service.
