Parker 11F32EC Coalescing Filter 46 Cfm 1/2 Inch Port

Product Description

The PARKER 11F32EC is a coalescing filter designed to remove oil aerosols, fine particulates, and water mist from compressed air lines. It serves as a critical inline filtration component in pneumatic systems, protecting downstream equipment such as valves, actuators, and air tools from contamination. The 11F32EC features a 1/2 inch port, a rated flow of 46 CFM, and a maximum operating pressure of 150 psi. The polycarbonate bowl provides visual monitoring of the collected liquid level, and the manual drain allows controlled condensate removal during service intervals. Licensed technicians and industrial service pros install this filter as part of a compressed air treatment train.

The 11F32EC is suited for use in residential, light commercial, and industrial compressed air systems where oil-free downstream air is required. Its modular connection design allows it to be combined with other Parker Modular Series filtration and regulation components, making it practical for building out multi-stage air treatment assemblies. Typical applications include spray finishing, pneumatic tool supply lines, process air systems, and any circuit where contamination control is critical to equipment longevity and output quality.

Key Features

• 0.01 micron filtration rating removes fine oil aerosols and submicron particulates from compressed air
• 1/2 inch port size with 46 CFM rated flow supports medium-duty pneumatic system demands
• 150 psi maximum operating pressure for compatibility with standard industrial compressed air supplies
• Polycarbonate bowl allows visual inspection of collected liquid without disassembly
• Manual drain enables controlled condensate removal during scheduled maintenance
• Modular connection design supports integration into multi-stage Parker filter and regulator assemblies

Compatibility

Designed as an OEM-style replacement and modular-series coalescing filter for compressed air treatment systems requiring a 1/2 inch port inlet and modular connection configuration.

Installation Notes

Installation of inline coalescing filters should be performed by a qualified pneumatic or industrial service technician. Always depressurize and lock out the compressed air supply before installing or servicing the filter. Ensure flow direction matches the arrow or markings on the filter body. The manual drain should be actuated regularly per system maintenance schedules to prevent condensate buildup that could carry over into downstream equipment.
