Parker 11F12EC Coalescing Filter 1/4 Inch Port 46 Cfm

Product Description

The PARKER 11F12EC is a coalescing filter designed to remove oil aerosols, fine particulates, and water droplets from compressed air lines. It features a 1/4 inch port, a rated flow capacity of 46 CFM, and a maximum operating pressure of 150 psi. The polycarbonate bowl allows visual inspection of collected contaminants without removing the filter from service. A manual drain handles liquid removal at the base. The modular connection design supports inline installation in compressed air distribution systems. This filter is typically installed by industrial maintenance technicians, HVAC mechanics, and pneumatic system specialists.

The 11F12EC is suited for light industrial and commercial compressed air applications where downstream equipment requires clean, dry, oil-free air. It fits inline on 1/4 inch compressed air supply lines ahead of regulators, lubricators, solenoid valves, air tools, and instrumentation. The compact form factor makes it practical for panel-mount or manifold installations where space is limited. Modular connection allows it to be combined with other filter-regulator-lubricator components in a series assembly.

Key Features

• 0.01 micron filtration rating removes oil aerosols and sub-micron particulates from compressed air
• 46 CFM rated flow capacity supports moderate compressed air demand applications
• 150 psi maximum operating pressure suits standard industrial compressed air systems
• Polycarbonate bowl provides visual monitoring of liquid accumulation without disassembly
• Manual drain for controlled removal of collected liquids at the bowl base
• Modular connection design allows integration into filter-regulator-lubricator assemblies

Compatibility

Designed as an OEM-style replacement or direct-fit coalescing filter for compressed air systems using 1/4 inch ported inline filtration components. Compatible with Parker modular compressed air preparation series that accept this form factor and port size.

Installation Notes

Installation is typically performed by qualified pneumatic or HVAC technicians. Depressurize and lock out the compressed air supply line before removing or installing any inline filter component. Verify that the upstream supply pressure does not exceed the 150 psi rated maximum. Inspect bowl and drain assembly for proper seating after installation before returning the system to operating pressure.
