Parker 10843-6-6 Hydraulic Hose 90 Degree Elbow 3/8 in

Product Description

The PARKER 10843-6-6 is a 90-degree elbow hydraulic hose fitting designed for connecting hydraulic hoses in high-pressure fluid systems. Machined from steel with a Female SAE threaded connection, this fitting accepts hoses with a 0.375-inch inside diameter (hose size 6). The overall installed length is 2.38 inches (60 mm). It is part of Parker's Series 43 fitting line and is installed by hydraulic technicians, industrial mechanics, and equipment service professionals working on mobile or stationary hydraulic systems.

This fitting is suited for use in both mobile equipment and stationary industrial hydraulic plumbing where a 90-degree directional change is required at the hose termination point. The threaded Female SAE interface provides a secure, leak-resistant connection when torqued to the appropriate system specification. Typical applications include agricultural equipment, construction machinery, and industrial hydraulic power units where routing constraints require an angled hose exit.

Key Features

• 90-degree elbow geometry for routing hoses in space-constrained hydraulic systems
• Steel construction for durability in high-pressure hydraulic service
• Female SAE threaded connection type for reliable sealing
• 0.375-inch (3/8-inch) hose inside diameter, hose size 6
• Overall length of 2.38 inches (60 mm)
• Parker Series 43 fitting — consistent with Parker hose assembly standards

Compatibility

Designed for use with Parker hose series: 187 TC, 187 ST, 302, 304, 387 TC, 387 ST, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487 TC, 487 ST, 722 TC, 722 ST, 787 TC, 787 ST, 797 TC, 797 ST, and 881 Hoses.

Installation Notes

Installation should be performed by a qualified hydraulic technician familiar with SAE threaded fitting assembly procedures. Depressurize and bleed the hydraulic system completely before removing or installing any fittings. Do not over-torque the threaded connection; refer to the system or equipment manufacturer's torque specifications for SAE threads of this size. Inspect the mating hose end and fitting threads for damage or contamination before assembly.
