Parker 10826-6-6 Sae 45 Jic Swivel Fitting 5/16 in Brass

Product Description

The PARKER 10826-6-6 is a straight female SAE 45-degree JIC swivel fitting designed for hydraulic hose assemblies. Machined from brass, it provides a threaded, swivel-style connection that reduces stress on hose ends during installation and system operation. The fitting accepts hoses with a 5/16-inch inside diameter and uses a 5/8-18 thread size. At 1.84 inches in overall length, it is a compact, direct-connect solution for routing hydraulic lines in tight installations. Licensed HVAC, plumbing, and fluid-power technicians routinely use fittings like this when assembling or repairing hydraulic circuits on mobile and stationary equipment.

This fitting is rated for hydraulic hose applications where a female SAE 45-degree JIC swivel connection is required at the hose end. The straight configuration suits runs where the hose approaches the port inline without requiring an angled adapter. It belongs to Parker Series 26 and is sized for hose size designation 5, corresponding to a 5/16-inch hose ID. Typical use cases include hydraulic power units, mobile machinery, and industrial fluid-transfer assemblies.

Key Features

• Straight female SAE 45-degree JIC swivel design reduces torque transfer to hose during tightening
• Brass construction provides corrosion resistance in hydraulic fluid environments
• 5/8-18 thread size mates with standard SAE 45-degree JIC ports
• 1.84-inch overall length suits compact plumbing layouts
• Swivel body allows hose positioning after the fitting is seated
• Parker Series 26 fitting — engineered for dimensional consistency across assemblies

Compatibility

Designed for use with Parker hose series 201, 206, 213, 221FR, 225, 244, 266, 285, 293, and SS23CG, all in hose size 5 (5/16-inch ID).

Installation Notes

Installation should be performed by a qualified fluid-power technician or pipefitter familiar with hydraulic system assembly. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Inspect threads and seating surfaces for damage before assembly. Tighten to the fitting and hose manufacturer specifications — do not over-torque brass fittings, as this can crack the body or distort the swivel seat.
