Parker -10754 Push-to-connect Tube Fitting 1/8 in Brass

Product Description

The PARKER -10754 is a push-to-connect tube-to-tube fitting designed for fast, tool-free connections in pneumatic and fluid control lines. Constructed from brass, it accepts 1/8-inch outside diameter tubing and is rated for a maximum working pressure of 150 psi. The fitting uses a nitrile O-ring seal to maintain a reliable, leak-resistant connection. It is commonly installed by HVAC technicians, heavy equipment mechanics, and fleet service professionals working on air-shift or seat-control systems. The compact form factor makes it practical in tight routing environments where speed of assembly matters.

This fitting is suited for use in air-shift transmission systems, seat control circuits, and dash control pneumatic lines. It is appropriate for both original-equipment assembly and field service repair scenarios. The push-to-connect design eliminates the need for threading tools or compression sleeves, reducing installation time on repetitive or high-volume service tasks. Applications are typically low-volume pneumatic lines operating at or below 150 psi.

Key Features

• Push-to-connect design allows tool-free tube insertion and secure retention
• Brass body construction for corrosion resistance in pneumatic service
• Nitrile O-ring seal provides reliable leak-resistant performance
• Rated to 150 psi maximum working pressure
• Accepts 1/8-inch OD tubing in a tube-to-tube configuration
• Sold in a package of 10 with a minimum order quantity of 1

Compatibility

Designed for use with air-shift transmission systems, seat controls, and dash controls. Fits 1/8-inch OD tubing in tube-to-tube push-to-connect configurations. Verify tubing material and system pressure before installation.

Installation Notes

Depressurize the pneumatic circuit completely before removing or installing any push-to-connect fittings. Ensure tubing ends are cut cleanly and squarely with no burrs that could damage the O-ring or prevent full seating. Insert tubing until it bottoms out in the fitting body to achieve a proper lock. After pressurizing the system, inspect the connection for leaks before returning the equipment to service.
