Parker 10643-8-10 Hydraulic Hose Female Swivel 90 Elbow

Product Description

The PARKER 10643-8-10 is a female swivel 90-degree elbow fitting designed for hydraulic hose assemblies. Manufactured from steel with a female JIC threaded connection, it accommodates a hose inside diameter of 0.625 inches and uses a 1/2-inch thread size. The fitting measures 2.82 inches in overall length and is part of PARKER Series 43. It is used to create a 90-degree directional change in a hydraulic line while maintaining a leak-resistant swivel connection. Licensed hydraulic technicians and industrial fluid-power mechanics install this type of fitting in high-pressure hose assemblies across mobile equipment, industrial machinery, and related hydraulic systems.

This fitting is suited for use in hydraulic hose assemblies requiring a 90-degree elbow transition with a female JIC swivel end. It is compatible with a wide range of PARKER hose series, including 187, 302, 304, 387, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487, 722, 787, 797, and 881 hoses, as well as TC and ST variants of applicable series. Typical applications include mobile hydraulic circuits, industrial power units, and equipment requiring tight routing geometries where a straight fitting is not practical.

Key Features

• Female swivel 90-degree elbow configuration allows directional routing without twisting the hose
• Female JIC threaded connection provides a secure, leak-resistant interface
• Steel construction suited for high-pressure hydraulic service
• 0.625-inch hose inside diameter with 1/2-inch thread size
• 2.82-inch overall length fits standard hose assembly clearances
• Meets ISO 12151-5 standards; California PROP 65 compliant

Compatibility

Designed for use with PARKER 187, 302, 304, 387, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487, 722, 787, 797, and 881 hydraulic hose series, including applicable TC and ST variants.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid-power mechanic. Depressurize and isolate the hydraulic circuit completely before disassembling any fittings or hose ends. Use appropriate wrenching flats and calibrated torque tooling per the system manufacturer's assembly specifications. Inspect thread engagement and swivel movement before returning the circuit to service.
