Parker 10027 Hydraulic Hose Female Pipe Rigid Fitting

Product Description

The PARKER 10027 is a female pipe rigid fitting designed for use in hydraulic hose assemblies requiring a secure, non-articulating threaded connection. Built from steel with a female NPSF thread configuration, this fitting accepts a 1/2 inch hose and uses a 1/2-14 thread size for a leak-resistant sealed connection. It carries a maximum working pressure rating of 3,000 psi, making it suitable for demanding hydraulic circuits in industrial and mobile equipment applications. Part of Parker's FF Series, it is installed by hydraulic system technicians and fluid power mechanics working on high-pressure plumbing assemblies.

This fitting is intended for use in hydraulic hose systems where a rigid female pipe connection is required at a termination or junction point. It is commonly found in industrial machinery, mobile equipment, and fluid power systems where 1/2 inch hose lines must transition to threaded port connections. The threaded design provides a dependable metal-to-metal seal suitable for high-pressure hydraulic circuits operating up to 3,000 psi. Its compact overall length of 2.75 inches supports installations in tight routing environments.

Key Features

• Maximum working pressure of 3,000 psi for high-pressure hydraulic service
• Female NPSF threaded connection provides a rigid, non-swivel interface
• Steel construction for durability in demanding fluid power environments
• 1/2-14 thread size with 1/2 inch hose compatibility
• Maximum flow rate of 12.00 GPM supports a wide range of hydraulic circuit demands
• Compact 2.75 inch overall length for use in space-constrained assemblies

Compatibility

Designed as an OEM-style replacement or service fitting for 1/2 inch hydraulic hose assemblies requiring a female NPSF rigid pipe connection rated to 3,000 psi.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power mechanic. Depressurize and fully isolate the hydraulic system before removing or installing any fittings. Inspect all mating threads for damage or contamination before assembly. Follow applicable industry standards and equipment manufacturer torque specifications when making threaded hydraulic connections.
