Parker 1.50TEF4MAU14A08.00 Rodless Air Cylinder

Product Description

The PARKER 1.50TEF4MAU14A08.00 is a double acting rodless air cylinder designed for linear motion applications in pneumatic systems. It features a 1-1/2 inch bore and an 8 inch stroke, delivering up to 250 psi of working pressure. The aluminum body keeps weight low at 3.9 pounds while maintaining structural integrity under continuous cycling. A 3/8 NPTF port provides a leak-resistant threaded connection. The cylinder measures 11-5/8 inches in overall length and 2 inches in overall width, making it suitable for compact installation envelopes. This component is typically installed by industrial maintenance technicians, mechanical contractors, and automation system integrators.

This rodless cylinder fits double acting pneumatic circuit designs where space constraints prevent the use of a traditional rod-style cylinder. The basic mount style allows for flexible positioning on machine frames, fixtures, and automated equipment. The 7/16-20 female rod thread provides a secure attachment point for end tooling or load brackets. With a nitrile butadiene rubber seal package, it is well suited for standard industrial air service in both light manufacturing and general automation environments.

Key Features

• Double acting design allows powered extension and retraction strokes
• 1-1/2 inch bore with 8 inch stroke for moderate force and travel range
• 250 psi maximum working pressure rated for standard industrial pneumatic systems
• Aluminum body construction reduces overall assembly weight
• 3/8 NPTF port delivers a leak-resistant threaded connection to air supply lines
• Nitrile butadiene rubber seals provide reliable performance in standard industrial air service

Compatibility

Designed as an OEM-style replacement or direct-fit component for double acting rodless pneumatic cylinder applications requiring a 1-1/2 inch bore, 8 inch stroke, basic mount configuration, and 3/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified maintenance technician or pneumatic systems integrator. Before servicing or replacing this cylinder, depressurize the pneumatic circuit completely and lock out the air supply in accordance with applicable OSHA lockout/tagout procedures. Verify that port fittings and thread sealants are compatible with NPTF connections before assembly. Do not exceed the 250 psi maximum working pressure rating during system commissioning or operation.
