Parker 1.50DXPSRM02.00 Rodless Air Cylinder 1.5 in Bore

Product Description

The PARKER 1.50DXPSRM02.00 is a double acting rodless air cylinder designed for use in pneumatic motion control applications. It features a 1.5-inch bore and a 2-inch stroke, making it well-suited for compact linear actuation tasks where a traditional rod-style cylinder would not fit. Built with a stainless steel body and nitrile butadiene rubber seals, it handles a maximum working pressure of 250 psi. The cylinder accepts a 1/8 NPTF port connection and supports double end or rear pivot mounting. Pneumatic system integrators and industrial maintenance technicians are the typical installers of this component.

This cylinder is used in light-duty to medium-duty pneumatic systems where space constraints require a rodless design. The 2-inch stroke suits short-travel linear positioning tasks in manufacturing, automation, and fluid handling equipment. The double end or rear pivot mount style allows flexible installation orientation depending on the machine frame or bracket configuration. The stainless steel body provides resistance to corrosion in washdown or moderately harsh environments.

Key Features

• Double acting operation for powered motion in both directions
• 1.5-inch bore with 2-inch stroke for compact linear travel
• Stainless steel body for corrosion resistance
• 250 psi maximum working pressure
• 1/8 NPTF port for standard pneumatic line connections
• Nitrile butadiene rubber seals for reliable air retention
• Double end or rear pivot mount supports flexible installation

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic systems requiring a rodless double acting cylinder with a 1.5-inch bore, 2-inch stroke, and 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician. De-pressurize and lock out the air supply before servicing or mounting this cylinder. Verify port thread compatibility with existing fittings before installation, as NPTF threads require appropriate sealant or tape on male connections. Ensure the mounting bracket or pivot hardware is rated for the operating pressure and load.
