Parker 1.25USU1602.00 Air Cylinder 1.25 in Bore 2 in Stroke

Product Description

The PARKER 1.25USU1602.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1.25-inch bore and a 2-inch stroke, delivering bidirectional actuation powered by compressed air on both the extend and retract cycles. The cylinder body is constructed from steel, aluminum, and stainless steel, with nitrile butadiene rubber seals rated for a maximum working pressure of 200 psi. The universal mount configuration allows flexible installation across a wide range of fixture orientations. This cylinder is installed by industrial maintenance technicians and pneumatic system integrators working with automated equipment and machine tooling.

This cylinder fits applications requiring compact linear actuation where a traditional rod-style cylinder would create clearance or space constraints. The rodless design keeps the overall installed length shorter relative to stroke travel. It suits light-duty to medium-duty pneumatic circuits in manufacturing, assembly, and material handling environments. The 1/8 NPTF port accepts standard pneumatic fittings and threaded connections common in industrial air circuits. The 3/8-24 male rod thread provides a direct mechanical interface to attached tooling or load-bearing hardware.

Key Features

• Double acting design provides powered motion in both directions
• 1.25-inch bore with 2-inch stroke for compact linear travel
• 200 psi maximum working pressure rating
• 1/8 NPTF port for standard pneumatic fitting connections
• Universal mount style accommodates multiple installation orientations
• Stainless steel body construction with nitrile butadiene rubber seals for durability
• 3/8-24 male rod thread for direct tooling attachment

Compatibility

Designed as an OEM-style replacement or new-installation component for industrial pneumatic systems requiring a double acting rodless cylinder with a 1.25-inch bore and universal mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. Depressurize and lock out the air supply before removing any existing cylinder or making port connections. Use thread sealant rated for pneumatic service on the NPTF port fittings and verify all connections are leak-free before returning the circuit to operating pressure. Confirm that the mounting hardware and load alignment are secure before cycling the cylinder under load.
