Parker 1.06DXPSRM08.00 Rodless Air Cylinder 8 in Stroke

Product Description

The PARKER 1.06DXPSRM08.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1-1/16 inch (1.06 inch decimal) bore and an 8 inch stroke, with a maximum working pressure of 250 psi. The cylinder body is constructed from stainless steel, making it suitable for applications where corrosion resistance is a priority. The 1/8 NPTF port accepts standard threaded pneumatic fittings, and the double end or rear pivot mounting style gives installers flexibility in how the unit is positioned and secured. Licensed pneumatic system technicians and industrial maintenance professionals are the primary installers of this component.

This cylinder is suited for use in light-duty industrial and automation applications where a compact, rodless design is required to conserve axial space. The 1.12 inch overall width and 12.78 inch overall length keep the envelope tight, making it a practical choice in confined machine frames or fixture assemblies. The double acting configuration allows air pressure to drive the piston in both directions, providing positive control on both the extend and retract strokes. It is appropriate for use in conveyor positioning, pick-and-place fixtures, and similar pneumatic automation tasks.

Key Features

• Double acting operation provides powered motion in both extend and retract directions
• Stainless steel body construction for corrosion resistance in demanding environments
• 1-1/16 inch bore with 8 inch stroke for compact linear travel
• 250 psi maximum working pressure rated for standard shop-air pneumatic circuits
• 1/8 NPTF port for secure, leak-resistant threaded fitting connections
• Double end or rear pivot mount style offers installation flexibility
• Nitrile butadiene rubber (NBR) seals compatible with standard pneumatic lubricants

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic cylinder for double acting rodless cylinder applications requiring a 1-1/16 inch bore, 8 inch stroke, and 1/8 NPTF porting with double end or rear pivot mounting.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Depressurize the pneumatic circuit and lock out the air supply before removing or installing this cylinder. Verify that supply pressure does not exceed 250 psi and that all fittings are compatible with 1/8 NPTF threads before applying pressure. Follow applicable machine safety standards and the equipment manufacturer guidelines when mounting and plumbing the cylinder.
