Parker 1.06DXPSRM03.00 Rodless Air Cylinder 1-1/16 in Bore

Product Description

The PARKER 1.06DXPSRM03.00 is a double acting rodless air cylinder designed for linear motion applications in industrial pneumatic systems. It features a 1-1/16 inch (1.06 inch decimal) bore and a 3 inch stroke, with a maximum working pressure of 250 psi. The body is constructed from stainless steel, making it suitable for environments where corrosion resistance is a priority. The cylinder uses a 1/8 NPTF port and includes NBR (nitrile butadiene rubber) seals. Installation is handled by licensed maintenance mechanics and industrial automation technicians working on pneumatic actuator assemblies.

This cylinder is suited for light-duty industrial pneumatic applications requiring compact, rodless linear actuation. The double end or rear pivot mount style gives installers flexibility in how the unit is secured to a machine frame or fixture. The 1.12 inch overall width keeps the footprint narrow in tight-space installations. The 5/16-24 male rod thread provides a standard connection interface for tooling or load attachments. Typical use cases include material handling, fixture clamping, and automated tooling on production equipment where a rodless profile reduces overall assembly length.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• Stainless steel body construction for corrosion-resistant service
• 250 psi maximum working pressure rating
• 1/8 NPTF port for standard pneumatic line connections
• Double end or rear pivot mount style for flexible installation orientation
• NBR seal material compatible with standard pneumatic circuit lubricants
• Compact 1.12 inch overall width for space-constrained assemblies

Compatibility

Designed as an OEM-style replacement or direct-fit rodless pneumatic cylinder for industrial automation systems requiring a 1-1/16 inch bore, 3 inch stroke double acting actuator with NPTF porting and double end or rear pivot mounting.

Installation Notes

Installation should be performed by a qualified pneumatics technician or industrial maintenance mechanic. Depressurize and lock out the pneumatic circuit completely before removing or installing the cylinder. Ensure port fittings and thread sealant are compatible with NPTF connections to prevent leaks under pressure. Do not exceed the 250 psi maximum working pressure rating for this cylinder.
