Parker 1.06DSRM08.00 Rodless Air Cylinder 1-1/16 in Bore 8 in

Product Description

The PARKER 1.06DSRM08.00 is a double acting rodless air cylinder designed for linear motion applications in pneumatic automation systems. It features a 1.06-inch bore diameter and an 8-inch stroke length, with a maximum working pressure rating of 250 psi. The body is constructed from stainless steel, making it suitable for environments where corrosion resistance is a priority. The 1/8 NPTF port accepts standard threaded pneumatic fittings, and the front nose mount configuration allows direct panel or fixture attachment. This cylinder is typically installed by industrial maintenance technicians, automation integrators, and mechanical contractors working on pneumatic motion control systems.

This cylinder suits light-duty to medium-duty pneumatic automation tasks where a compact, rodless design saves space along the travel axis. The front nose mount style fits applications where the cylinder body needs to be anchored at the nose end to a bracket or machine frame. The 1.12-inch overall width and 11.91-inch overall length keep the footprint minimal. The 5/16-24 male rod thread accommodates standard coupling hardware for connecting to driven loads.

Key Features

• Double acting design allows powered extension and retraction via separate air ports
• Stainless steel body provides corrosion resistance in washdown or humid environments
• 250 psi maximum working pressure suits most plant air supply systems
• 1/8 NPTF port integrates with standard pneumatic fittings and manifold blocks
• Front nose mount simplifies panel or bracket installation without secondary hardware
• Nitrile butadiene rubber seals provide reliable performance across a broad temperature range

Compatibility

Designed as an OEM-style replacement or direct installation component for pneumatic automation systems requiring a double acting rodless cylinder with a 1.06-inch bore and front nose mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. Depressurize and lock out the air supply before removing an existing cylinder or installing this unit. Verify that supply pressure does not exceed 250 psi and that port fittings are rated for the application pressure. Follow applicable OSHA lockout/tagout procedures and any site-specific pneumatic safety standards when servicing this component.
