Parker 1.06DSRM04.00 Rodless Air Cylinder 1-1/16 in Bore

Product Description

The PARKER 1.06DSRM04.00 is a double acting rodless air cylinder designed for linear pneumatic motion in industrial automation and manufacturing applications. Built with a stainless steel body and nitrile butadiene rubber seals, it delivers reliable, corrosion-resistant performance across a wide range of duty cycles. The cylinder features a 1-1/16 inch (1.06 inch decimal) bore and a 4 inch stroke, rated to a maximum working pressure of 250 psi. The 1/8 NPTF port accepts standard compressed-air fittings. Licensed pneumatic technicians and industrial maintenance mechanics are the primary installers of this component.

This cylinder is suited for use in space-constrained linear motion systems where a traditional rod-style cylinder would not fit or would create side-load problems. The rodless design allows the load to travel the full stroke length without extending beyond the cylinder envelope. The front nose mount style supports direct panel or bracket mounting in both horizontal and vertical orientations. Typical applications include conveyor positioning, pick-and-place fixtures, and slide table actuators in light-to-medium duty production equipment.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• Stainless steel body for corrosion resistance in wash-down or humid environments
• Nitrile butadiene rubber seals compatible with standard lubricated or non-lubricated compressed air
• 1/8 NPTF port size accepts common push-to-connect and barbed pneumatic fittings
• Front nose mount style for straightforward panel or bracket installation
• 250 psi maximum working pressure suits standard plant air supply systems

Compatibility

Designed as an OEM-style replacement or direct-fit component for double acting rodless pneumatic cylinder applications requiring a 1-1/16 inch bore, 4 inch stroke, front nose mount, and 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic technician or industrial maintenance mechanic. Depressurize and lock out the air supply before removing an existing cylinder or connecting pneumatic lines. Verify that supply air pressure does not exceed the 250 psi maximum working pressure rating. Ensure port fittings are properly sealed with thread sealant rated for compressed air service, and confirm the mounting bracket or nose plate is secured to prevent lateral loading on the cylinder body.
