Parker 1.06DSRM02.00 Rodless Air Cylinder 1-1/16 Bore 2 Stroke

Product Description

The PARKER 1.06DSRM02.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1-1/16 inch (1.06 inch decimal) bore and a 2 inch stroke, with a maximum working pressure rating of 250 psi. The body is constructed from stainless steel, making it well suited for environments that demand corrosion resistance. A nitrile butadiene rubber (NBR) seal package provides reliable sealing under standard pneumatic service conditions. This cylinder is typically installed by maintenance technicians, automation specialists, or industrial pipefitters working on pneumatic motion systems.

This cylinder is suited for compact linear actuation applications where a traditional rod-style cylinder is not practical or where space constraints require a low-profile design. The front nose mount configuration allows straightforward panel or bracket mounting on machinery, production equipment, or automated assembly fixtures. With a 1/8 NPTF port, it connects directly to standard pneumatic supply lines. The overall width of 1.12 inches keeps the assembly footprint minimal. Applications span light industrial automation, material handling, and general factory pneumatic circuits requiring repeatable bidirectional linear motion.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• Stainless steel body construction for corrosion resistance in demanding environments
• 250 psi maximum working pressure for standard industrial pneumatic supply systems
• 1/8 NPTF port threads for leak-resistant connection to pneumatic supply lines
• Front nose mount style allows direct panel or bracket installation
• NBR seal material compatible with standard compressed air and light lubricated air service

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic automation systems requiring a double acting rodless air cylinder with a 1-1/16 inch bore, 2 inch stroke, and front nose mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Depressurize and lockout the pneumatic supply before removing or installing the cylinder. Ensure all port connections use compatible NPTF thread sealant and do not overtighten fittings into the aluminum or stainless port threads. Verify that the mounting hardware is torqued to the fixture manufacturer's specification and that the cylinder alignment is true to avoid side-loading the bore during operation.
