Parker 1.06DSRM01.50 Rodless Air Cylinder 1-1/16 Bore

Product Description

The PARKER 1.06DSRM01.50 is a double acting rodless air cylinder designed for pneumatic linear motion applications in industrial and automation systems. It features a 1-1/16 inch (1.06 inch decimal) bore and a 1-1/2 inch stroke, with a maximum working pressure of 250 psi. The body is constructed from stainless steel, making it well-suited for environments requiring corrosion resistance. The cylinder uses a 1/8 NPTF port and mounts via a front nose configuration. The rod diameter measures 0.312 inches with a 5/16-24 male thread. Pneumatic technicians and industrial maintenance professionals install this unit in compact linear motion systems where a traditional rod-style cylinder would exceed available envelope space.

This cylinder is intended for use in industrial automation, machine tooling, and material handling applications where precise, bidirectional linear actuation is required. The front nose mount style allows integration into panel or bracket assemblies with a clean forward-facing profile. The stainless steel body and nitrile butadiene rubber (NBR) seals make it appropriate for light-duty washdown or moderately humid industrial environments. Its compact overall width of 1.12 inches suits tight installation envelopes common in multi-axis pneumatic assemblies.

Key Features

• Double acting design provides positive force in both extend and retract directions
• Stainless steel body offers corrosion resistance in demanding environments
• 250 psi maximum working pressure supports a wide range of shop-air systems
• 1/8 NPTF port threads directly onto standard pneumatic fittings without sealant tape concerns
• NBR seals deliver reliable performance across typical industrial temperature ranges
• Front nose mount simplifies bracket or panel integration with a minimal footprint

Compatibility

Designed as an OEM-style pneumatic cylinder for industrial automation systems requiring a double acting rodless cylinder with a 1-1/16 inch bore, 1-1/2 inch stroke, front nose mount, and 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize and lock out the pneumatic supply line before mounting or removing the cylinder. Ensure all port connections are properly fitted and the mounting hardware is torqued to the bracket manufacturer specifications. Verify system supply pressure does not exceed the 250 psi rated maximum during operation.
