Parker 1.06DSRM01.00 Rodless Air Cylinder 1-1/16 in Bore

Product Description

The PARKER 1.06DSRM01.00 is a double acting rodless air cylinder designed for linear motion applications in pneumatic systems. It features a 1-1/16 inch (1.06 inch decimal) bore and a 1 inch stroke, with a maximum working pressure of 250 psi. The cylinder body and rod are constructed from stainless steel, making it suitable for environments where corrosion resistance is required. A 1/8 NPTF port provides the air connection, and the front nose mount style allows direct inline installation. Licensed HVAC, mechanical, and automation technicians will find this cylinder appropriate for compact actuator applications requiring reliable bidirectional force.

This cylinder is suited for light-duty industrial and automation installations where a compact double acting design is required. The front nose mount configuration supports straightforward in-line mounting on pneumatic fixtures, tooling, and mechanical assemblies. With a stainless steel body and nitrile butadiene rubber (NBR) seals, the cylinder is appropriate for applications involving moderate moisture exposure or environments where stainless construction is specified. It is sized for systems operating at or below 250 psi with a 1-1/16 inch bore requirement.

Key Features

• Double acting design delivers controlled force in both extension and retraction directions
• 1-1/16 inch bore with 1 inch stroke for compact linear motion
• Stainless steel body construction for corrosion resistance
• Nitrile butadiene rubber (NBR) seals rated for standard pneumatic service
• 1/8 NPTF port compatible with standard pneumatic fittings
• Front nose mount style for direct inline installation

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic systems requiring a double acting rodless air cylinder with a 1-1/16 inch bore, 1 inch stroke, front nose mount, and 1/8 NPTF port.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician familiar with compressed air systems. De-pressurize and lock out the air supply before removing or installing this cylinder. Verify that all fittings and port threads are clean and undamaged before making connections. Consult applicable system documentation and safety codes for mounting torque and tubing specifications not listed here.
