Parker 1.00USU1602.00 Rodless Air Cylinder 1in Bore 200psi

Product Description

The PARKER 1.00USU1602.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1 inch bore and a 2 inch stroke, with a maximum working pressure of 200 psi. The body is constructed from steel, aluminum, and stainless steel, with nitrile butadiene rubber seals for reliable performance across a range of industrial environments. The 1/8 NPTF port accepts standard compressed air fittings. Ports are threaded to NPTF standards to prevent leakage without sealant tape in properly torqued connections. Licensed HVAC, mechanical, and industrial maintenance technicians install this type of cylinder in automated equipment and process machinery.

This cylinder is suited for light-duty industrial and commercial pneumatic automation applications where a compact rodless design is required. The universal mount style allows flexible installation orientation, making it adaptable to a variety of equipment configurations. With a 0.313 inch rod diameter and a 5/16-18 rod thread, it connects directly to standard pneumatic actuator hardware. It is appropriate for use in material handling, positioning, and machine automation tasks where 200 psi compressed air supply is available.

Key Features

• Double acting operation for powered extension and retraction
• 1 inch bore with 2 inch stroke in a compact 4.87 inch body length
• 200 psi maximum working pressure
• 1/8 NPTF port for leak-resistant threaded connections
• Stainless steel and aluminum construction with nitrile butadiene rubber seals
• Universal mount style for flexible installation orientation

Compatibility

Designed as an OEM-style pneumatic cylinder for use in standard compressed air systems operating at up to 200 psi with 1/8 NPTF port connections and 5/16-18 rod thread hardware.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pneumatic systems professional. Depressurize and lock out the compressed air supply before removing or installing any pneumatic component. Verify that the supply air pressure does not exceed 200 psi and that the air supply is clean, dry, and lubricated as required by the application. Secure all port connections fully to NPTF thread engagement standards before returning the system to service.
