Parker 1.00USU1601.00 Rodless Air Cylinder 1 in Bore 200 Psi

Product Description

The PARKER 1.00USU1601.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. With a 1 inch bore and 1 inch stroke, it delivers bidirectional force using compressed air acting on both sides of the piston. The cylinder body is constructed from steel, aluminum, and stainless steel, with nitrile butadiene rubber seals rated for continuous service. Maximum working pressure is 200 psi. The 1/8 NPTF port connects to standard pneumatic supply lines. This cylinder is installed by industrial maintenance technicians and automation specialists in equipment requiring compact, rod-free linear actuation.

This cylinder fits applications where space constraints prevent the use of a conventional rod-style cylinder. The rodless design allows the full stroke length to be used within the envelope of the cylinder body itself. Typical installations include material handling fixtures, positioning stages, and light-duty automation assemblies in industrial and manufacturing environments. The universal mount style supports flexible orientation during installation. The 5/16-18 male rod thread provides a standard attachment point for tooling or load brackets.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• 1 inch bore with 200 psi maximum working pressure for reliable force output
• Stainless steel and aluminum body construction for corrosion resistance and light weight
• Nitrile butadiene rubber seals suitable for standard compressed air service
• 1/8 NPTF port for leak-resistant connection to pneumatic supply lines
• Universal mount style allows flexible positioning in the assembly
• 5/16-18 male rod thread for direct attachment to load hardware

Compatibility

Designed as an OEM-style replacement or new-installation rodless air cylinder for pneumatic automation systems requiring a 1 inch bore double acting configuration with universal mounting.

Installation Notes

Installation should be performed by a qualified pneumatic technician or industrial maintenance professional. Depressurize and lock out the pneumatic supply before removing or installing the cylinder. Use thread sealant rated for compressed air on the NPTF port connections and verify all fittings are secure before pressurizing. Do not exceed the 200 psi maximum working pressure rating during system commissioning or operation.
