Parker 08FS5C2332ACF Solenoid Valve 1/2 in Npt Brass

Product Description

The PARKER 08FS5C2332ACF is a direct-acting, normally closed solenoid valve designed for control of hot water and steam in commercial and industrial fluid systems. The brass body houses an EPDM seal rated to 300 degrees F and supports a maximum working pressure of 50 psi. With a Cv factor of 3.6 and a 1/2-inch orifice, the valve delivers reliable flow control for high-temperature media. It accepts a wide range of coil voltages including 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60 to 110/50 Vac, and 240/60 to 220/50 Vac, making it adaptable to varied control-circuit configurations. Licensed plumbers, HVAC technicians, and industrial pipefitters typically install this valve as part of zone control or process-isolation assemblies.

This valve is suited for residential and commercial hot water and steam applications where a fail-closed, de-energized-closed action is required. The 1/2-inch NPT threaded connection integrates directly into standard pipe configurations. The 11-watt coil draw keeps heat generation low in panel-mounted or enclosed installations. CSA, UL, and NEMA 4X ratings make it appropriate for wet or wash-down environments where listed components are required by code or specification.

Key Features

• Direct-acting, normally closed operation — closes immediately on power loss
• Brass body with EPDM seal rated to 300 degrees F for hot water and steam service
• 1/2-inch NPT port with 0.5-inch orifice and Cv of 3.6 for high-flow capacity
• Multi-voltage coil compatibility: 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60-110/50 Vac, 240/60-220/50 Vac
• 11-watt coil wattage minimizes heat buildup in control enclosures
• CSA Certified, UL Listed, and NEMA 4X rated for use in demanding environments

Compatibility

Rated for hot water and steam applications. Designed as a direct-acting solenoid valve replacement or new installation for systems requiring a normally closed, 1/2-inch NPT brass valve with EPDM sealing and multi-voltage coil support.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable local codes and ASME or IFGC guidelines. Shut off and depressurize the system and allow it to cool completely before removing or installing the valve. Verify coil voltage matches the control circuit before energizing. Note that solenoid coils are sold separately and are not included with this valve body.
