PARKER 08F23C6140ACF4C05 2-Way Solenoid Valve

Product Description

The PARKER 08F23C6140ACF4C05 is a 2-way solenoid valve designed for reliable performance in various applications. This valve has a standard port size of one-half inch NPT and features a durable body made from 316 stainless steel. It is ideal for use with air, liquids, and gases while maintaining a minimum pressure differential of zero PSI and a maximum of one hundred fifty PSI.

• Valve Type: 2-Way
• Port Size: 1/2 inch NPT
• Seal Material: NBR

Product Highlights

This valve is suitable for controlling media such as air, water, light oil, and inert gas. It can operate effectively in environments with varying pressure differentials.

Product Information

Standard Information

• Brand: PARKER
• MPN: 08F23C6140ACF4C05

Technical Specifications

• Series: Gold Ring Series
• Valve Type: 2-Way
• Function: Normally Closed
• Input Voltage: 110-120 VAC at 50/60 Hz
• Body Material: 316 Stainless Steel
• Seal Material: NBR
• Orifice: 5/8 in
• Flow Factor (CV): 4
• Power Consumption: 11 W
• Coil Type: 1/2 NPT Conduit, 18 Leads, Class F, NEMA 4X
• Maximum Pressure Differential: 150 PSI (AC)
• Number Of Ports/Ways: 2-Way
• Actuation: Internal Pilot Operated
• Media: Air, Water, Light Oil, Inert Gas
• Port Type: NPT
• Minimum Pressure Differential: 0 PSI
• Minimum Fluid Temperature: 0 °F
• Maximum Fluid Temperature: 180 °F
• Enclosure: NEMA 4, 4X
• Electrical Connection: 18 in Leads
• Industry Standards: UL Listed and CSA Certified
• Width: 2.81 in
• Depth: 2.28 in
• Inlet Center To Top Of Valve: 3.28 in
• Anti-Water Hammer: No
• Pressure Rating: 0 PSI Minimum, 150 PSI Air/Inert Gas, 150 PSI Water, 150 PSI Light Oil
• Temperature Rating: 180 °F
• Coil Insulation Class: Class 155
