Parker 06F23C6140ACF 2-way Solenoid Valve 3/8 Inch Npt

Product Description

The PARKER 06F23C6140ACF is a 2-way, normally closed, piloted diaphragm solenoid valve designed for control of fluids, gases, and light oils in industrial and mechanical systems. The valve body is constructed from stainless steel with an NBR seal, making it suitable for demanding service environments. It operates on AC power at 11 watts and supports a maximum working pressure of 150 psi with a minimum operating pressure differential of 0 psi, allowing it to open against zero differential pressure when energized. Note that solenoid coils are not included and must be sourced separately. Licensed HVAC technicians, plumbers, and pipefitters are the typical installers for this type of valve in fluid or gas control applications.

The 06F23C6140ACF is suited for residential and commercial applications where automated shut-off or flow control is required for liquids, gases, or light oil service. The 3/8 inch NPT port size fits standard pipe configurations common in HVAC, refrigeration, water treatment, and light industrial piping systems. Its zero minimum pressure differential rating makes it viable in low-pressure or gravity-fed systems where standard pilot-operated valves would not function reliably. ASCO Number 8210G37 is associated with this valve for cross-reference purposes.

Key Features

• 2-way piloted diaphragm design with normally closed unactuated state
• Stainless steel body for corrosion resistance in fluid and gas service
• NBR seal material compatible with water, air, and light oil media
• Zero minimum operating pressure differential — suitable for low-pressure systems
• 11-watt AC coil power requirement; solenoid coil not included
• Cv factor of 3.0 for predictable flow sizing and system design

Compatibility

Cross-references to ASCO Number 8210G37. Designed as an OEM-style replacement or upgrade solenoid valve body for 3/8 inch NPT piping in fluid, gas, and light oil control systems. Verify coil compatibility separately before installation.

Installation Notes

Installation should be performed by a licensed plumber, pipefitter, or HVAC technician in accordance with applicable local mechanical codes and IFGC or IPC requirements for the media being controlled. De-energize the system and isolate the line pressure before removing or installing the valve. Solenoid coils are not included with this valve body and must be ordered and verified for compatibility before commissioning. Do not exceed the 150 psi maximum working pressure rating.
