Parker 0474725 Xtreme Plus® 25x25x1 inches Standard Capacity Pleated Filter

Product Description

The PARKER 0474725 XTREME+Plus® standard-capacity, self-supported pleated (SSP) air filter with Airguard® technology achieves MERV 8 mechanical efficiency and provides low pressure drop and industry-leading dust-holding capacity. Designed for use in commercial HVAC applications with normal operating environments and low to medium dust loading conditions. Not recommended for use in high-temperature or turbulent-airflow environments.

• Self-supported media — no metal wire backing means no corrosion or deformation of metal
• Consistent pleat shape and spacing allow particulates to collect evenly over the entire surface of the media. Pleat stabilizer straps add rigidity and maintain proper pleat spacing.
• Over 140 adhesion points between the media and the frame

Product Highlights

The XTREME+Plus® filter maintains performance and structural integrity in wet or humid conditions. The synthetic media is resistant to moisture, mold, and mechanical damage and is fully incinerable for environmentally friendly disposal.

Product Information

Standard Information

• Brand: PARKER
• Manufacturer Part Number: 0474725
• Country of Origin: Domestic

Technical Specifications

• Dimensions: 25 x 25 x 1 in
• MERV: 8
• Series: Xtreme Plus
• Temperature Rating: 150 deg F
• Disposable: Yes
• Filter Efficiency Rating: 70% at 3.0 to 10 Micron
• Flow Rate: 415 to 2170 cfm
• Frame Material: Paperboard
• Initial Resistance: 0.15 to 0.22 w.g.
• Manufacturer: Parker Hannifin
• Manufacturer #: 0474725
• Pleat Separator Type: Self Supporting
• Rated Air Velocity: 300 ft/min
• Sub-Brand: Airguard
• Thickness: 1 in
• Type: Standard Capacity
• Depth: 1 in
• Filter Type: Pleated
• Height: 25 in
• Material: Synthetic Fiber
• Material Type: Polyester
• Maximum Temperature: 150
• Origin: Domestic
• Size: 25 in x 25 in x 1 in
• UL Listed: Yes
• Width: 25 in
• Division: HVAC Filtration Division
• Nominal Filter Size: 25x25x1
• Filtration efficiency: MERV 8, MERV-A 8-A
• Rated air velocities (fpm): 300–500
• Air flow rates (cfm): 415–2170
• Final resistance (in.w.g.): 1.0
• Maximum operating temperature: 150 °F (65 °C)
• Material of construction: single-piece, moisture-resistant, beverage board frame
• Classified per UL 900: for flammability only
