Parker 0.75USU1604.00 Rodless Air Cylinder 0.75in Bore 4in

Product Description

The PARKER 0.75USU1604.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 0.75 inch bore and a 4 inch stroke, with a maximum working pressure of 200 psi. The body is constructed from steel, aluminum, and stainless steel, making it suitable for applications where corrosion resistance and structural durability are both required. Seals are nitrile butadiene rubber (NBR), compatible with standard compressed air and many industrial fluids. This cylinder is installed by maintenance technicians, automation specialists, and industrial mechanics in factory and process environments.

This cylinder is suited for light-duty to medium-duty pneumatic automation tasks in both OEM machine builds and field maintenance replacement scenarios. The universal mount style offers flexible mounting configurations without requiring dedicated brackets, which reduces setup time on new builds and retrofits. The 1/8 NPTF port integrates directly with standard pneumatic fittings and manifolds. The 0.25 inch rod diameter with 1/4-20 rod thread allows direct connection to clevis fittings, tooling plates, and actuator accessories commonly used in industrial automation assemblies.

Key Features

• Double acting operation for positive force in both extend and retract directions
• 0.75 inch bore with 4 inch stroke for compact linear travel in tight envelopes
• 200 psi maximum working pressure for standard industrial pneumatic supply compatibility
• Stainless steel and aluminum construction with NBR seals for durability and corrosion resistance
• Universal mount style accommodates multiple mounting orientations without specialty hardware
• 1/8 NPTF port for direct connection to standard pneumatic fittings and supply lines

Compatibility

Designed as an OEM-style replacement or new-installation pneumatic cylinder for standard industrial automation systems using 0.75 inch bore double acting cylinder configurations with universal mount and 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified industrial mechanic or automation technician. Depressurize the pneumatic supply line completely before removing or installing any cylinder. Verify that supply pressure does not exceed 200 psi and that fittings are torqued according to fitting manufacturer specifications. Ensure the mounting surface is square and rigid to prevent side-loading the rod, which can accelerate seal and bearing wear.
