Parker 0.75USU1603.00 Rodless Air Cylinder 0.75in Bore 200psi

Product Description

The PARKER 0.75USU1603.00 is a double acting rodless air cylinder designed for linear motion applications in pneumatic systems. With a 0.75 inch bore and 3 inch stroke, it delivers controlled bidirectional actuation at working pressures up to 200 psi. The cylinder body is constructed from steel and aluminum with stainless steel components, and seals are made from nitrile butadiene rubber (NBR) for reliable performance across a range of operating conditions. Port connections are 1/8 inch NPTF. The universal mount configuration allows flexible installation in tight or unconventional fixture arrangements. Licensed HVAC, plumbing, and industrial maintenance technicians commonly install this type of cylinder in automated control assemblies.

This cylinder suits light-duty to medium-duty pneumatic automation in both commercial and industrial settings. Typical applications include valve actuation, clamping fixtures, guided linear stages, and machine tool accessories where a compact, rodless design is preferred to minimize overall assembly length. The 1/4-20 male rod thread provides straightforward mechanical attachment to end-effectors or load brackets. The universal mount style accommodates a variety of mounting orientations without requiring specialized hardware.

Key Features

• Double acting operation provides powered motion in both extension and retraction directions
• 0.75 inch bore with 3 inch stroke in a compact rodless form factor
• 200 psi maximum working pressure rating
• 1/8 inch NPTF port for standard pneumatic line connections
• Steel and aluminum body with stainless steel components for corrosion resistance
• NBR seals compatible with standard compressed air service
• Universal mount style supports multiple installation orientations

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic cylinder for industrial automation assemblies requiring a 0.75 inch bore, 3 inch stroke, double acting rodless configuration with 1/8 inch NPTF porting and universal mount.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Depressurize and lock out the air supply before removing or installing any cylinder. Ensure port fittings are rated for at least 200 psi and that all thread connections are sealed appropriately for compressed air service per applicable safety codes. Do not exceed the rated working pressure, and verify that the mounting structure can support the cylinder under full load conditions.
