Parker 0.75DXPSRM02.00 Rodless Air Cylinder 3/4 in Bore

Product Description

The PARKER 0.75DXPSRM02.00 is a double acting rodless air cylinder designed for compact linear motion applications in pneumatic systems. It features a 3/4 inch bore diameter and a 2 inch stroke length, with a maximum working pressure rating of 250 psi. The cylinder body is constructed from stainless steel, making it well suited for environments where corrosion resistance is a priority. Port connections are 1/8 NPTF, and the rod thread size is 1/4-28. Nitrile butadiene rubber (NBR) seals are used throughout. Mounting options include double end or rear pivot configurations. Licensed HVAC, automation, and industrial maintenance professionals install and service this type of actuator.

This rodless air cylinder is intended for use in compact pneumatic actuator applications where traditional rod-style cylinders would require excess linear space. The double acting design allows controlled force in both extend and retract directions using shop air or a dedicated compressed air supply. With an overall width of 0.86 inches and a body length of 6.53 inches, it fits into tight panel or bracket-mounted assemblies. The double end or rear pivot mount style supports a range of fixture and bracket configurations in industrial and light commercial settings.

Key Features

• Double acting operation provides powered motion in both directions
• Stainless steel body construction for corrosion resistance
• NBR seal material for reliable performance with standard compressed air
• 1/8 NPTF ports for direct connection to standard pneumatic fittings
• 1/4-28 rod thread size for compatibility with standard mounting hardware
• Double end or rear pivot mount supports multiple installation orientations

Compatibility

Designed as an OEM-style replacement or drop-in actuator for pneumatic systems requiring a double acting rodless cylinder with a 3/4 inch bore, 2 inch stroke, and 1/8 NPTF port connections.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize the pneumatic system and bleed all residual air pressure before removing or installing the cylinder. Verify that supply line pressure does not exceed the 250 psi maximum working pressure rating. Secure all port fittings with appropriate thread sealant rated for pneumatic service and confirm mount bracket alignment before returning the system to operation.
