Parker 0.75DSRM06.00 Rodless Air Cylinder 0.75 in Bore 6 in

Product Description

The PARKER 0.75DSRM06.00 is a double acting rodless air cylinder designed for linear pneumatic motion control in industrial and automation applications. Built with a stainless steel body, it features a 0.75 inch bore, a 6 inch stroke, and a maximum working pressure rating of 250 psi. The 1/8 NPTF port accepts standard compressed air fittings, and the front nose mount configuration simplifies integration into existing pneumatic assemblies. This cylinder is installed by industrial maintenance technicians and automation engineers working with pneumatic motion systems.

This rodless cylinder is suited for light-duty linear actuation where a compact profile and corrosion-resistant construction are required. The stainless steel body makes it appropriate for environments where moisture or mild chemical exposure is a concern. With a 0.75 inch bore and 6 inch stroke, it fits standard pneumatic circuit designs requiring short-to-mid range travel in a space-constrained layout. The front nose mount style allows direct attachment to machine frames or brackets without complex tooling.

Key Features

• Double acting design allows powered extension and retraction via compressed air
• Stainless steel body provides corrosion resistance in demanding environments
• 250 psi maximum working pressure suits standard shop air systems
• 1/8 NPTF port compatible with standard pneumatic fittings
• Front nose mount style simplifies direct frame or bracket installation
• Nitrile butadiene rubber (NBR) seals for reliable air retention across typical operating temperature ranges

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic linear motion assemblies requiring a 0.75 inch bore, 6 inch stroke rodless cylinder with a front nose mount and 1/8 NPTF port connection.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pneumatic systems integrator. Depressurize and lock out the air supply before servicing or installing this cylinder. Ensure all fittings and port connections are properly sealed to prevent air leaks before returning the system to operating pressure. Do not exceed the 250 psi maximum working pressure rating under any operating condition.
