Parker 0.75DSRM03.00 Rodless Air Cylinder 0.75in Bore 250psi

Product Description

The PARKER 0.75DSRM03.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 0.75 inch bore, a 3 inch stroke, and a stainless steel body rated to 250 psi maximum working pressure. The front nose mount style allows for direct inline installation in tight actuator assemblies. With a rod diameter of 0.25 inches and a 1/4-28 male rod thread, this cylinder integrates cleanly into existing pneumatic circuits. Licensed mechanics and automation technicians working on factory, process, or OEM equipment are the primary installers.

This cylinder suits light-duty linear actuation tasks in industrial and manufacturing environments. The 1/8 NPTF port size accommodates standard pneumatic fittings used in compressed-air distribution systems. The rodless design keeps the overall footprint compact, making it appropriate for space-constrained motion stages, slide tables, and pick-and-place mechanisms. The nitrile butadiene rubber (NBR) seals provide reliable performance across a broad range of dry and lightly lubricated air applications.

Key Features

• Double acting operation provides powered motion in both extend and retract directions
• Stainless steel body for corrosion resistance in wash-down or humid environments
• 250 psi maximum working pressure suits standard shop-air and industrial pneumatic systems
• 1/8 NPTF port accepts common pneumatic push-to-connect and compression fittings
• Front nose mount style simplifies inline and panel installation
• NBR seal material compatible with dry air and lightly lubricated compressed-air circuits

Compatibility

Designed as an OEM-style replacement or direct-fit rodless air cylinder for pneumatic linear motion assemblies requiring a 0.75 inch bore, 3 inch stroke, and front nose mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance mechanic. Depressurize and lock out the air supply before removing any existing cylinder or fittings. Confirm port thread compatibility before connecting air lines, as NPTF threads require proper sealant or tape to prevent leaks under pressure. Verify that system operating pressure does not exceed the 250 psi rated maximum.
