Parker 0.75DSRM01.00 Rodless Air Cylinder 0.75in Bore 250psi

Product Description

The PARKER 0.75DSRM01.00 is a double acting rodless air cylinder designed for compressed air automation systems. It features a 0.75 inch bore and a 1 inch stroke, with a maximum working pressure of 250 psi. The body is constructed from stainless steel, making it well suited for environments where corrosion resistance matters. A 1/8 NPTF port connects the cylinder to the pneumatic circuit, and the rod thread is sized at 1/4-28 for standard actuator connections. Licensed millwrights, maintenance technicians, and automation specialists typically install this component as part of linear motion control assemblies on industrial equipment.

This cylinder fits applications requiring compact linear actuation without an external rod extending beyond the cylinder body. The front nose mount style allows direct panel or fixture mounting in tight equipment frames. Common installation scenarios include pick-and-place fixtures, clamping mechanisms, and slide assemblies in light to medium industrial automation. The stainless steel body and nitrile butadiene rubber seals make it appropriate for use in environments with occasional moisture or mild fluid exposure.

Key Features

• Double acting design uses air pressure for both extend and retract strokes
• Stainless steel body provides corrosion resistance in industrial environments
• 0.75 inch bore with 1 inch stroke for compact linear motion
• 250 psi maximum working pressure for reliable actuation force
• 1/8 NPTF port for secure, leak-resistant pneumatic connections
• Nitrile butadiene rubber seals compatible with standard compressed air service

Compatibility

Designed as an OEM-style replacement or new-installation rodless air cylinder for standard industrial pneumatic systems requiring a 0.75 inch bore, front nose mount configuration with 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified maintenance technician or automation specialist. Depressurize and lock out the pneumatic circuit before removing or installing any cylinder component in accordance with OSHA lockout/tagout procedures. Verify port thread engagement is correct for NPTF fittings to prevent air leaks at operating pressure. Do not exceed the rated 250 psi working pressure during system commissioning or testing.
