Panduit UGB2/0-414-6 StructuredGround Universal Grd Bar, 6 L

Product Description

The Panduit UGB2/0-414-6 StructuredGround Universal Ground Bar is designed to securely terminate the main equipment grounding conductor in control panels or enclosures. It accommodates a wide range of wire sizes with six ports and allows for connection of up to a 2/0 AWG conductor. The UGB2/0-414-6 supports mounting options suitable for various installations, such as bonding stand-offs and direct mounting to panels.

• Accepts wire sizes from #14 to #4 AWG in six ports
• Allows connection of up to 2/0 AWG main grounding conductors
• Various mounting options increase installation versatility

Product Highlights

The Panduit UGB2/0-414-6 is a versatile grounding bar ideal for use in control panels across different applications. Its design simplifies the termination of grounding conductors, making it suitable for both new installations and upgrades.

Product Information

Standard Information

• Catalog Number: UGB2/0-414-6
• Manufacturer: Panduit

Technical Specifications

• Material: Copper
• Color: Silver
• Length: 4.92 inches
• Width: 0.62 inches
• Height: 0.48 inches
• Standards: UL 467 and CSA certified 22.2 no.41
• UPC: 074983402229
• Item Type: Grounding Busbar
