Panduit PSN16-C Pan-Term Parallel Splice 20 AWG - 16 AWG

Product Description

The Panduit PSN16-C is a nylon insulated parallel splice designed to connect or lengthen wires. Constructed from brass with a tin-plated finish, this Pan-Term splice ensures a secure and reliable connection. It supports wire sizes from 20 AWG to 16 AWG and is rated for up to 300V.

• Designed to splice two solid or stranded wires together to repair or lengthen wires
• Parallel design results in only one crimp required to complete splice
• Seamless tubular barrel provides a consistent high performance quality crimp

Product Highlights

The Panduit PSN16-C parallel splice offers a reliable solution for wire splicing with its durable construction and easy crimp design.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: PSN16-C
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: PSN16-C
• Manufacturer: Panduit
• Brand: Panduit
• Sub Brand: Pan-Term
• Country of Origin: Mexico
• Made in USA: No
• Color: Blue
• Connection: Standard
• Finish: Tin-Plated
• Insulation: Nylon
• Material: Brass
• UPC: 074983833023
• GTIN: 00074983833023
• Item Type: Parallel Splice
• Temperature Rating: 221 Degrees Fahrenheit (105 Degrees Celsius)
• Voltage Rating: 300
• Wire Size: 20 AWG - 16 AWG AWG
• UNSPSC: 39121409
• Conductor Size: 20 to 16
• Wire Strip Length: 5/16
• Series: PSN
• Conductor Type: Stranded Copper
• Barrel Outer Diameter: 0.21
