Panduit PS18-C Parallel Splice Non-Insulated 2000 V (Pack of 100)

Brand: PANDUIT
SKU: PS18-C
Availability: In Stock

Ships same day if ordered by 12 pm
$56.49
$56.49
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Panduit PS18-C is a non-insulated parallel splice designed for joining two conductors in 22–18 AWG wire sizes. The PS18-C features a seamless tin-plated brass tubular barrel with crimp termination, rated to 2,000 V and 150 C (302 F). It accepts two wire entries in a parallel design that completes the splice with a single crimp and is supplied in standard 100-piece packaging.

  • Non-insulated seamless tin-plated brass tubular barrel for 22–18 AWG conductors
  • Parallel two-wire design requires one crimp; crimp termination
  • Rated to 2,000 V and 150 C (302 F); meets UL 486C and CSA C22.2 No.65

Product Highlights

Seamless tin-plated brass barrel; parallel two-wire crimp splice for 22–18 AWG; 2,000 V and 150 C rating; 100 per pack.

Product Information

Standard Information

  • Brand: PANDUIT
  • Manufacturer Part Number: PS18-C
  • Country of Origin: Mexico
Technical Specifications
Manufacturer
Panduit
Brand
PANDUIT
Manufacturer Part Number
PS18-C
Product Type
Parallel splice, non-insulated
Series
Pan-Term PS Series
Wire Gauge
22-18 AWG
Wire Size (Metric)
0.5 - 1 mm^2
Material
Brass
Finish
Tin-plated
Insulation
Non-Insulated
Termination
Crimp
Number of Wire Entries
2
Barrel Type
Seamless tubular
Barrel Length
0.29 in (7.4 mm)
Overall Length
0.29 in (7.4 mm)
Overall Width
0.13 in (3.3 mm)
Voltage Rating
2,000 V
Temperature Rating
150 C (302 F)
Standards Met
UL 486C; CSA C22.2 No.65
Package Quantity
100 per pack
RoHS Status
RoHS3 Compliant
Country of Origin
Mexico
Status
Discontinued
UPC
074983834006
UNSPSC
39121400
HTS
8535.90.80.20
