Panduit PN22-8R-C Ring Terminal Connector (22-26 AWG / #8 Stud / Pack 100)

Product Description

Panduit PN22-8R-C is a nylon-insulated ring terminal designed for crimp termination of 22-26 AWG conductors to a #8 stud. The terminal uses a tin-plated copper contact with a polyamide (nylon) insulation grip sleeve and is intended for secure bolted electrical connections. It measures 0.780 in overall length with a 0.260 in width and is rated to 300 V and 221 F (105 C).

• Nylon (polyamide) insulated ring terminal for 22-26 AWG conductors; fits #8 stud
• Tin-plated copper contact with crimp termination and insulation grip sleeve
• Dimensions: 0.780 in length, 0.260 in width, 0.090 in insulation diameter; contact thickness 0.020 in

Product Highlights

Nylon-insulated Pan-Term ring terminal; crimp termination for 22-26 AWG; #8 stud; tin-plated copper; 300 V / 105 C rating

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: PN22-8R-C
• Country of Origin: Japan
