Panduit PISR2-1 Splicer-Reducer 600V 14 AWG - 2 AWG Aluminum/PVC

Product Description

The Panduit PISR2-1 is a dual-rated in-line splicer/reducer. It is designed for use with both stranded aluminum and copper conductors, accommodating sizes from 14 AWG to 2 AWG. The splicer features clear PVC insulation, which eliminates the need for taping and allows for easy visual inspection of connections.

• Flexible design for splicing or reducing
• Insulated with clear PVC for visibility
• Pre-filled with oxidation inhibiting joint compound

Product Highlights

This splicer/reducer provides premium performance with high strength, extruded aluminum construction, ensuring durable electrical contact. It is UL Listed and CSA Certified for safe use up to 600 volts and rated for a maximum temperature of 90 degrees Celsius.

Product Information

Standard Information

• Manufacturer: Panduit
• Part Number: PISR2-1

Technical Specifications

• Conductor Size: 14 AWG to 2 AWG
• Voltage Rating: 600 VAC
• Temperature Rating: 90 deg C
• Dimensions: 2.38 inches L x 0.75 inches W x 1.25 inches H
• Material: Aluminum/PVC
• UPC: 074983421497
• UNSPSC: 39121458
• Standards: UL Listed, CSA Certified
