Panduit NKP5E88MWH NK CAT5E PUNCHDOWN JACK MODULE WHITE

Product Description

Panduit NKP5E88MWH is a keystone jack module designed for unshielded applications. This punchdown jack module supports Cat 5e standards and features eight positions, making it suitable for various network setups. It is built from ABS and polycarbonate materials, ensuring durability and long-term use.

• Compatible with various faceplates, patch panels, and surface mount boxes
• Color-coded label for T568A and T568B wiring schemes
• 100% tested for performance and individual traceability

Product Highlights

This module allows for quick and secure cable termination with industry-standard styles. Ideal for high-volume installations, it minimizes waste by eliminating the need to open individual packages.

Product Information

Standard Information

• Application: For unshielded applications
• Color: White

Technical Specifications

• Manufacturer Part Number: NKP5E88MWH
• Material: ABS/Polycarbonate
• Module Type: Cat 5e/Keystone
• Mounting Type: Surface
• Standards/Approvals: ANSI/TIA-1096-A, ANSI/TIA-568-C.2, ANSI/TIA-568.2-D, ARRA Compliant, Buy American Act Compliant, IEC 60603-7, IEEE 802.3af/802.3at/802.3bt Type 3/Type 4, RoHS Compliant, UL 1863/2043
• Dimensions: 0.65 in W x 1.16 in D x 0.9 in H
• Type: 1-Slot 8-Position 8-Wire Punchdown Unshielded
