Panduit LCC4/0-38DW-X Copper Compression Lug 2 Hole

Product Description

The PANDUIT LCC4/0-38DW-X is a two-hole copper compression lug designed for terminating large-gauge conductors in high-current electrical installations. Compression lugs of this type create a gas-tight mechanical bond between the conductor and the lug barrel when crimped with the appropriate tooling, reducing resistance at the termination point and improving long-term connection reliability. This lug is sized for 4/0 AWG conductors and features a dual-hole mounting tongue for secure attachment to bus bars, switchgear terminals, or panel studs. Licensed electricians and electrical contractors install this type of fitting in commercial and industrial power distribution work.

Two-hole copper compression lugs in the 4/0 AWG range are commonly used in service entrance equipment, main distribution panels, motor control centers, and switchgear assemblies. The dual-hole tongue prevents the lug from rotating on the mounting surface after installation, which is a critical feature in high-vibration environments or where torque on a single fastener could compromise the connection. This fitting is sold as an individual piece and is appropriate for both new construction and maintenance or retrofit applications.

Key Features

• Two-hole mounting tongue prevents rotation and maintains secure contact at terminal surfaces
• Copper construction provides high conductivity and corrosion resistance at the termination point
• Compression-style barrel creates a gas-tight crimp bond when installed with compatible tooling
• Sized for 4/0 AWG conductor termination
• Sold individually for single-point replacement or small-quantity installations

Compatibility

Designed as an OEM-style compression termination lug for 4/0 AWG copper conductors used in residential service entrance, commercial panel, and industrial power distribution applications.

Installation Notes

Installation must be performed by a licensed electrician in accordance with applicable NEC requirements. Always de-energize and lock out the circuit before terminating any conductors. Use only manufacturer-recommended compression tooling and the correct die index for the conductor size and lug barrel to achieve a proper crimp. Do not use open-barrel lugs on aluminum conductors unless the fitting is explicitly rated for aluminum.
