Panduit LCB1-38-E Pan-Lug LCB Copper Compression Connectors - Lugs 1 AWG 3/8 IN

Product Description

The PANDUIT LCB1-38-E Pan-Lug LCB Copper Compression Connector is a one-hole, long barrel lug designed for secure electrical connections. Suitable for #1 AWG wire and a 3/8 stud hole. It features a durable tin plating that enhances corrosion resistance and ensures long-lasting performance. This lug is an excellent choice for high-quality electrical installations.

• Suitable for #1 AWG wire
• Features a 3/8 inch stud hole
• Made from tin-plated copper

Product Highlights

The PANDUIT LCB1-38-E lug ensures reliable and long-lasting performance for power and grounding applications.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: LCB1-38-E
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: LCB1-38-E
• Manufacturer: Panduit Corp
• Brand: Panduit
• Sub Brand: Pan-Lug
• Country of Origin: Mexico
• Made in USA: No
• Material: Tin-Plated Copper
• Number of Holes: 1
• Special Features: Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
• Standard: C22.2 No. 65-13, 486A-486B File #E52164
• UPC: 074983432691
• GTIN: 00074983432691
• Item Type: Compression Lug
• Size: #1 AWG Code
• Stud Size: 3/8 IN
• Category: Connectors, Interconnects
• Terminals: Lugs
• Mounting Type: Free Hanging (In-Line)
• Termination: Crimp, Barrel
• Series: Pan-Lug
• Wire Gauge: 1 AWG
• Packaging: Bulk
• Insulation: Non-Insulated
• Part Status: Active
• Terminal Type: Rectangular Tongue
• Contact Finish: Electro-Tin
• Contact Material: Copper
• Terminal Style: Single Stud Hole
• Diameter - Barrel ID: 0.360" (9.14mm)
• Tab Thickness: 0.110" (2.79mm)
• Diameter - Barrel OD: 0.470" (11.94mm)
• Length - Overall: 2.570" (65.28mm)
• Diameter - Ring ID: 0.410" (10.41mm)
• Width - Outer Edges: 0.700" (17.78mm)
• Finish: Tin-Plated
• Stud Hole Spacing: 3/8 in.
• Lug Wire Size: 1 AWG
• Length: 2.57 in.
• Product Name: Terminal Connector
• Product Type: Terminal Connector
• Environmentally Friendly: Yes
• Conductor Size: 1 AWG
• Conductor Type: Copper/Stranded
• Die Code: P37
• Temperature Rating: 90 3.2639999999968423
