Panduit KA22-1/0 Hex Crimp Die 6 Ton Ka22 Series

Product Description

The PANDUIT KA22-1/0 is a 6-ton hex crimp die designed for use with Ka22 Series compression crimping tools. It delivers a consistent, repeatable hex crimp profile suited for terminating lugs, connectors, and splices on copper and aluminum conductors. Electricians and wire harness technicians rely on this die to achieve code-compliant, low-resistance terminations on properly sized conductors. The die seats into compatible Ka22 Series tool frames and indexes correctly to prevent misalignment during the crimp cycle.

This crimp die is used in commercial and industrial electrical work where reliable conductor terminations are required. Typical applications include panel wiring, power distribution, and service entrance connections where 1/0 AWG conductors are terminated to compression-style connectors and lugs. It is sold as an individual unit, making it a practical replacement or additional die for shops and field crews already running Ka22 Series tooling.

Key Features

• 6-ton crimp force rating for consistent hex compression results
• Sized for 1/0 AWG conductors to match common power wiring applications
• Designed for Ka22 Series crimp tool frames for positive tool-to-die fit
• Hex crimp profile provides uniform compression around the connector barrel
• Sold as a single unit for targeted replacement or tooling expansion

Compatibility

Designed as an OEM-style replacement or supplemental die for Ka22 Series 6-ton compression crimping tools.

Installation Notes

Installation of this crimp die should be performed by a qualified electrician familiar with compression termination tooling. De-energize all conductors and verify the circuit is locked out and tagged out before beginning any termination work. Ensure the die is fully seated and indexed in the tool frame before initiating the crimp cycle. All compression terminations should comply with applicable NEC requirements for the conductor size and connector type being used.
