Panduit FZ2ELLNSNSNM008 OM4 Duplex Lc Fiber Patch Cable

Product Description

The PANDUIT FZ2ELLNSNSNM008 is a 2-fiber OM4 duplex fiber optic patch cable designed for high-density data center and network infrastructure applications. It features an LC duplex connector configuration on both ends with a 1.6mm low-smoke zero-halogen (LSZH) jacket, making it suitable for environments where fire safety and smoke toxicity are regulated. The polished contact (PC) end-face finish reduces back-reflection and insertion loss. Licensed network technicians and structured cabling installers work with this cable in core switching, server interconnect, and patch panel applications.

This patch cable is used in OM4 multimode fiber runs supporting 10G, 40G, and 100G network speeds over short to medium distances in commercial and enterprise environments. The LSZH jacket designation makes it appropriate for plenum-adjacent or enclosed spaces where halogen-free materials are required by local fire codes or building standards. Typical install scenarios include structured cabling closets, data center top-of-rack switching, and fiber distribution frames.

Key Features

• OM4 multimode fiber supports high-bandwidth applications including 40G and 100G ethernet
• LC duplex connectors on both ends for standard small-form-factor port compatibility
• 1.6mm LSZH jacket reduces smoke and halogen emissions in enclosed or restricted spaces
• PC-polished end faces provide low insertion loss and reduced back-reflection
• 2-fiber duplex construction supports full-duplex transmit and receive in a single cable

Compatibility

Designed as an OEM-style replacement or standard patch cable for OM4 multimode fiber infrastructure using LC duplex ports in structured cabling and data center environments.

Installation Notes

Installation is performed by certified fiber optic technicians or structured cabling installers. Clean all LC connector end faces with an appropriate fiber optic cleaning tool before mating to transceivers or adapters. Avoid bending the cable tighter than the rated minimum bend radius to prevent signal degradation. Follow TIA-568 and local building codes when routing cables through walls, ceilings, or equipment enclosures.
