Panduit FSCMCXAQ Fiber Optic Connector Laser Optimized Pre-Polished SC-Simplex 50/125 um OM3/OM4 Multi-Mode

Product Description

The Panduit FSCMCXAQ is a fiber optic connector designed for SC-Simplex connections. It features laser optimized pre-polished technology for 50/125 um OM3/OM4 multi-mode fiber. This connector is suitable for use with 900 um tight buffered cable and incorporates a zirconia ceramic ferrule for reliable performance.

• Factory pre-polished fiber eliminates field polishing.
• Average insertion loss of 0.3 dB per mated pair.
• Allows for up to two re-terminations without performance degradation.

Product Highlights

This fiber optic connector streamlines installation by reducing the time and tools required for termination. Its design minimizes operator error, leading to high yield rates in installations.

Product Information

Standard Information

• Brand: Panduit
• Part Number: FSCMCXAQ

Technical Specifications

• Type: SC-Simplex
• Fiber Type: 50/125 um OM3/OM4 Multi-Mode
• Cable Construction: 900 um Buffered Fiber
• Ferrule Type: Zirconia Ceramic
• Insertion Loss: 0.3 dB
• Return Loss: >26 dB
• Color: Aqua
• Country of Origin: CR
