Panduit F9TYP5EL2SAF090 OS2 12-fiber Trunk Cable

Product Description

The PANDUIT F9TYP5EL2SAF090 is a pre-terminated OS2 single-mode fiber optic trunk cable designed for structured cabling infrastructure in commercial and enterprise environments. It features a 12-fiber configuration with an MPO female connector on one end and LC duplex connectors on the other, making it a breakout-style trunk assembly suitable for high-density fiber distribution. The cable jacket is rated OFNP (optical fiber nonconductive plenum), qualifying it for installation in air-handling spaces without conduit. Network technicians and low-voltage cabling contractors are the primary installers of this assembly.

This trunk cable is used in backbone and horizontal runs within data centers, telecommunications rooms, and enterprise LAN environments. The MPO-to-LC duplex configuration supports 12 individual LC duplex connections fanned out from a single MPO interface, a common architecture in structured fiber distribution systems using cassettes or patch panels. Its plenum-rated jacket makes it appropriate for above-ceiling and open-plenum cable pathways where fire code compliance is required.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation signal transmission
• 12-fiber count supports multiple duplex LC connections from one MPO interface
• OFNP plenum-rated jacket meets fire code requirements for air-handling spaces
• MPO female to LC duplex breakout configuration for high-density distribution
• Factory pre-terminated for consistent insertion loss and plug-and-play deployment

Compatibility

Designed as an OEM-style replacement and infrastructure component for OS2 single-mode MPO-based fiber distribution systems using standard MPO female and LC duplex interfaces.

Installation Notes

Installation should be performed by a qualified low-voltage cabling contractor or network infrastructure technician familiar with fiber optic handling practices. Avoid exceeding the minimum bend radius of the cable during routing, as exceeding it can cause signal degradation or physical damage to the fiber. Ensure all MPO and LC connectors are cleaned with approved fiber optic cleaning tools before mating. Local fire and building codes, including NFPA 70 (NEC), govern plenum cable installation requirements and should be consulted before pulling cable in air-handling spaces.
