Panduit F9TYL5EL2SAM035 OS2 12-fiber Trunk Cable

Product Description

The PANDUIT F9TYL5EL2SAM035 is a pre-terminated OS2 single-mode fiber optic trunk cable designed for high-density structured cabling installations. It features a 12-fiber configuration with an MPO connector on one end and LC duplex connectors on the other, making it a standard breakout assembly for connecting backbone runs to patch panels or active equipment. The Low Smoke Zero Halogen (LSZH) jacket reduces toxic gas and smoke emissions in the event of a fire, meeting the requirements of plenum-sensitive and life-safety-critical environments. Network technicians and low-voltage cabling contractors are the primary installers of this assembly.

This trunk cable assembly is suited for data center backbone cabling, enterprise structured cabling systems, and telecommunications rooms where OS2 single-mode fiber is specified. The MPO-to-LC duplex fanout configuration supports direct connection between high-density MPO panels or cassettes and individual LC-interfaced transceivers or patch panels. LSZH jacketing is commonly required in European installations and in domestic projects where building codes restrict halogen-containing cable materials in air-handling spaces and enclosed pathways.

Key Features

• OS2 single-mode fiber supports long-distance, low-attenuation transmission
• 12-fiber count in a single MPO connector simplifies high-density backbone routing
• MPO to LC duplex breakout configuration enables direct equipment-side patching
• LSZH jacket reduces smoke and toxic halogen gas emission in fire conditions
• Pre-terminated factory assembly provides consistent insertion loss and eliminates field termination

Compatibility

Designed as a standard OS2 MPO-to-LC duplex trunk assembly compatible with MPO adapter panels, cassette modules, and LC-interfaced equipment in single-mode structured cabling systems.

Installation Notes

Installation should be performed by qualified low-voltage cabling technicians familiar with fiber optic handling procedures. Inspect connector end-faces with an appropriate fiber microscope and clean per industry standards before mating. Observe minimum bend radius requirements for the cable throughout routing and termination to avoid attenuation or physical damage. All fiber pathways should be installed in compliance with applicable codes including ANSI/TIA-568 and local building codes governing LSZH cable use.
