Panduit F9TRP5NQSSNF019 OS2 12-fiber Mpo Harness

Product Description

The PANDUIT F9TRP5NQSSNF019 is an OS2 single-mode 12-fiber MPO harness cable with OFNP plenum-rated jacket. This assembly converts a single MPO connector on the trunk side into individual fiber legs on the distribution side, allowing high-density fiber routing in structured cabling systems. The plenum rating makes it suitable for installation in air-handling spaces without requiring conduit. Licensed low-voltage cabling technicians and network infrastructure installers are the primary trades working with this assembly.

This harness is used in backbone and horizontal fiber distribution runs within data centers, enterprise LAN environments, and telecommunications rooms. It is designed to interface with MPO-based patch panels, fiber cassettes, and pre-terminated trunk cable systems. The OS2 single-mode fiber type supports long-distance, high-bandwidth transmission over 9-micron core glass, making it appropriate for inter-building or long-run intra-building links.

Key Features

• OS2 single-mode 12-fiber construction for high-bandwidth long-distance runs
• MPO connector on the feeder end for compatibility with high-density MPO panels and cassettes
• OFNP plenum-rated jacket meets fire and smoke requirements for air-handling plenum spaces
• Factory-terminated harness assembly reduces field termination labor and error
• Sold as an individual assembly (quantity of one per unit)

Compatibility

Designed as an OEM-style replacement and standard harness assembly for use with MPO-based high-density fiber distribution systems in single-mode OS2 infrastructure.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician following TIA-568 structured cabling standards. Verify that all MPO connectors are fully seated and that dust caps are removed prior to mating. Avoid sharp bend radii below the minimum specified for single-mode fiber to prevent signal loss. In plenum spaces, confirm the OFNP jacket rating satisfies the local authority having jurisdiction before installation.
