Panduit F92ERQ1Q1SNM1.5 OS2 Fiber Patch Cable

Product Description

The PANDUIT F92ERQ1Q1SNM1.5 is an OS2 single-mode fiber optic patch cable designed for structured cabling installations in commercial and industrial environments. Built with a 2-fiber 1.6mm jacketed construction and rated OFNR (Optical Fiber Nonconductive Riser), this cable meets riser-rated fire code requirements for vertical runs between floors. The push-pull connector design allows for clean, tool-free insertion and extraction in high-density fiber panels where adjacent connectors would otherwise make standard pull-tabs difficult to reach. Licensed electricians and low-voltage cabling technicians are the primary installers of this type of fiber assembly.

This patch cable is suited for backbone and horizontal fiber runs in commercial buildings, data centers, and telecommunications rooms where OS2 single-mode transmission is specified. The OFNR rating makes it appropriate for plenum-adjacent riser shafts when a full plenum-rated cable is not required. The 1.6mm jacket diameter is common in high-density patching environments where space at the panel face is limited. It is sold as a single cable assembly per unit.

Key Features

• OS2 single-mode fiber optimized for long-distance, low-attenuation transmission
• 2-fiber construction in a compact 1.6mm jacket for high-density installations
• OFNR (Optical Fiber Nonconductive Riser) fire rating for vertical riser runs
• Push-pull connector housing enables easy extraction in congested patch panels
• PC (Physical Contact) polish on connectors reduces back-reflection at the mating interface

Compatibility

Designed as an OEM-style single-mode OS2 fiber patch cable for use with standard fiber optic patch panels, wall plates, and equipment ports accepting push-pull style connectors with PC-polished ferrules.

Installation Notes

Installation should be performed by a licensed low-voltage technician or electrician familiar with fiber optic handling procedures. Avoid exceeding the minimum bend radius of the cable during routing to prevent signal loss or fiber damage. Clean all connector ferrules with appropriate fiber optic cleaning tools before mating. Verify riser pathway fire-stop requirements with local AHJ when routing through rated assemblies.
