Panduit F92ERLNSNSNM043 OS2 Duplex Fiber Patch Cable Lc

Product Description

The PANDUIT F92ERLNSNSNM043 is an OS2 single-mode duplex fiber optic patch cable designed for structured cabling and data network installations. Built with a 1.6mm diameter cable jacket and LC duplex connectors on both ends, this 2-fiber assembly is rated OFNR (Optical Fiber Nonconductive Riser), making it suitable for vertical runs between floors in commercial buildings. It is installed by network technicians and low-voltage cabling specialists in data centers, telecom rooms, and enterprise LAN environments. The OS2 single-mode designation supports long-distance, high-bandwidth transmission with low signal loss.

This patch cable is used in structured cabling applications where riser-rated fiber is required between floors or in vertical cable pathways. Typical installations include patch panel connections in telecom closets, switch-to-server runs in data centers, and backbone fiber links in commercial or institutional buildings. The LC duplex form factor is common in high-density fiber installations where space is limited and secure latching connectors are preferred. This cable is sold as an individual assembly, quantity one per unit.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation optical transmission
• LC duplex connectors on both ends for high-density patching applications
• 1.6mm cable diameter for flexible routing in tight pathways
• OFNR-rated jacket approved for riser installations per NEC Article 770
• 2-fiber construction supports full-duplex data communication
• Factory-terminated assembly eliminates field polishing and reduces installation time

Compatibility

Designed as an OEM-style replacement or standard patch cable for use with LC duplex single-mode fiber equipment in riser-rated structured cabling systems.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician familiar with fiber optic handling practices. Power down connected active equipment before disconnecting or connecting fiber patch cables to prevent damage to optical transceivers. Avoid exceeding the minimum bend radius of the cable during routing, and protect connectors with dust caps when not in use. Riser installations must comply with NEC Article 770 requirements for OFNR-rated optical fiber cabling.
