Panduit F92ERB1SNSNM009 OS2 Lc Apc Fiber Patch Cord

Product Description

The PANDUIT F92ERB1SNSNM009 is a single-mode OS2 duplex fiber optic patch cord terminated with LC APC connectors on both ends. It features a 1.6mm cordage diameter and an OFNR (Optical Fiber Nonconductive Riser) rated jacket, making it suitable for in-building riser pathways. The 9-meter cable length supports structured cabling runs between patch panels, switches, transceivers, and active equipment in data centers, telecom rooms, and enterprise network environments. Installation is typically performed by low-voltage cabling technicians and network infrastructure professionals.

This patch cord is designed for OS2 single-mode fiber applications where low insertion loss and high return loss are required over longer horizontal or riser runs. The LC APC connector type, with its angled physical contact polish, reduces back-reflection and is commonly specified in passive optical network (PON) infrastructure, fiber-to-the-desk deployments, and high-density patching environments. The duplex configuration supports full-duplex transceiver connections standard in most enterprise and data center switch deployments.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation signal transmission
• LC APC connectors on both ends with angled physical contact polish for reduced back-reflection
• 1.6mm cordage diameter for flexible routing in high-density patching environments
• OFNR-rated jacket meets riser flame spread requirements for in-building vertical runs
• Duplex construction supports full-duplex transceiver operation
• 9-meter length provides reach for rack-to-rack or panel-to-equipment connections

Compatibility

Designed as an OEM-style replacement and standard-fit patch cord for OS2 single-mode LC APC fiber infrastructure in riser-rated structured cabling installations.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician following TIA-568 and applicable local codes. Always power down active ports or disable laser sources before handling fiber connectors to avoid eye hazard from infrared emissions. Inspect and clean LC APC ferrules with an appropriate fiber optic cleaning tool before mating to prevent contamination-related loss. Do not exceed the minimum bend radius of the cordage during routing or dressing.
