Panduit F92ERANB1SNM010 OS2 Fiber Patch Cord Sc/apc

Product Description

The PANDUIT F92ERANB1SNM010 is an OS2 single-mode fiber optic patch cord designed for low-loss, high-bandwidth structured cabling installations. Built with a 1.6mm diameter cable, dual-fiber (2F) construction, and SC/APC connectors on each end, this patch cord delivers the angled physical contact terminations required to minimize back-reflection in sensitive optical links. The OFNR (Optical Fiber Nonconductive Riser) rating qualifies it for riser-rated cable pathways. Network technicians, low-voltage contractors, and data center installers use this cord for patching OS2 single-mode runs at the equipment or distribution point.

This patch cord is suited for structured cabling environments where single-mode OS2 fiber is deployed, including enterprise data centers, telecom rooms, campus backbone runs, and commercial building networks. It is intended for use where SC/APC connector interfaces are specified at patch panels, transceivers, or optical distribution frames. The 10-meter length makes it practical for longer cross-connect runs within a rack room or between adjacent enclosures. Installation is performed by low-voltage cabling technicians and network infrastructure crews.

Key Features

• OS2 single-mode fiber for long-distance, high-bandwidth optical transmission
• SC/APC connectors with angled physical contact terminations for reduced back-reflection
• 1.6mm cable diameter provides a compact, flexible form factor for dense patching environments
• 2-fiber (duplex) construction supports full-duplex data links
• OFNR rating qualifies the cord for installation in riser-rated cable pathways per applicable codes
• 10-meter length accommodates longer patch runs within equipment rooms

Compatibility

Designed as an OEM-style patch cord for use with SC/APC-interfaced fiber optic equipment, patch panels, and optical distribution frames in OS2 single-mode structured cabling systems.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician familiar with fiber optic handling practices. Inspect SC/APC ferrule end-faces for contamination before mating and clean per standard fiber cleaning procedures. Do not exceed the minimum bend radius of the cable during routing. Riser-rated OFNR cables must be installed in accordance with NEC Article 770 riser pathway requirements.
