Panduit F92ERANB1SNM004 OS2 Duplex Fiber Patch Cable

Product Description

The PANDUIT F92ERANB1SNM004 is an OS2 singlemode duplex fiber optic patch cable terminated with SC/APC connectors on each end. Designed for low-loss, long-distance data transmission, this cable carries a 1.6mm cordage diameter and a 2-fiber configuration rated OFNR (Optical Fiber Nonconductive Riser) for riser-rated plenum and vertical runs inside buildings. Polished with a physical contact (PC) finish, the connectors minimize back-reflection and insertion loss. Network technicians and low-voltage installers use this cable to interconnect equipment in structured cabling systems, patch panels, and active optical equipment.

This patch cable is suited for enterprise, data center, and commercial network installations where OS2 singlemode fiber infrastructure is already in place. The OFNR jacket rating makes it appropriate for vertical cable runs between floors in accordance with NEC riser requirements. The SC/APC connector type is commonly found in passive optical network (PON) and telecommunications applications where low back-reflection is critical.

Key Features

• OS2 singlemode fiber for long-distance, low-attenuation signal transmission
• SC/APC connectors with physical contact polish for reduced insertion loss and back-reflection
• Duplex 2-fiber construction supports simultaneous transmit and receive paths
• 1.6mm diameter cordage for flexible routing in tight spaces
• OFNR-rated jacket approved for riser installations per NEC Article 770

Compatibility

Designed as a standard SC/APC duplex patch cable compatible with OS2 singlemode fiber optic equipment, patch panels, and wall plates equipped with SC/APC adapter ports.

Installation Notes

Installation is performed by low-voltage technicians or structured cabling professionals. Power down or place active optical equipment in a safe state before connecting or disconnecting fiber patch cables to prevent eye hazard from live laser sources. Do not bend the cable below its minimum bend radius during routing. Follow NEC Article 770 requirements for fiber optic cabling in riser environments.
